Reversible lift-off hinge PD-129
New product
Reversible lift-off hinge, Spanish standard.
Suitable for both wide groove (Series 6000) and narrow groove (Series 4000).
Fixing with zamak clamping shoes makes it very easy to install and adjust.
The security grub screw included in the clamping shoes gives it exceptional strength.
Contents:
- 2 fixing shoes.
- 4 raised countersunk screws M5x10.
- 2 security grub screws.
- 1 shaft.
Capacity:
- For openings up to 2,000 x 1,000 mm.
- Up to 60 kg: 2 units.
- Up to 70 kg: 3 units.
Materials:
- Extruded aluminium hinges.
- Zamak clamping shoes.
- Stainless steel screws.
- Steel or stainless steel shaft.
Finishes:
- Anodised.
- Powder coated in RAL colours.
Packaging:
Box of 100 units.
